Product Overview

Introducing the Danlers Ceiling Surface Mounted PIR Occupancy Switch White (CESFPIR) – a hard wired switch which can be mounted on a square pattress box. They are ideal for solid ceilings where automated lighting control is required. Includes passive infrared technology to detect motion, illuminating your surroundings only when needed. CESFPIR is ideal for meeting rooms, offices, corridors, student accommodation, etc.

Absence detection feature:
When the occupant leaves the room or detection area, the PIR automatically turns off the lights after a predetermined time.
The override OFF function allows occupants to turn off the lights using the wall switch while the CEFLA PIR is in the ON state, bypassing the pre-selected time lag. To turn the lights back ON, simply operate the wall switch as usual.

Energy efficiency:
Thanks to the PIR technology, the switch is designed to detect occupancy and automatically turn lights on and off, reducing energy consumption and lowering electricity bills.

Specifications:
·  Detection zone: 360° 5m at 2.4m high

Detection range:

·   Up to 7m (5m strong detection and 2m secondary detection)
·   Time lag range: 10 seconds to 40 minutes in 9 steps
·   Photocell range: 30 to 1000 lux, and inactive

Loading:
o   Up to 6 amps (1500W) of resistive loads
o   Up to 6 amps (1500W) of fluorescent loads
o   Up to 3 amps (750W) of electronic and wire wound transformer loads
o   Up to 2 amps (500W) of CFL, 2D lamps, LED Drivers and LED lamps and fittings
o   Up to 1 amp (250W) of fans

Downloads

Download danlers-ceflapir

Specification

Battery Backup	Yes
Cable Length	2m
Current Amps	6A
Detectors Per Zone	360
Domestic or Commercial	Domestic, Commercial
Frequency	50Hz
Material	Fire Resistant Polycarbonate
Motion Detection	Yes
Mounting	Ceiling
PIR Fitted	Yes
power consumption	1500W
Sensor	PIR Motion Sensor
Type Of Switch Socket	PIR
Voltage	230V
Wattage	1500W
Depth	68mm
