Danlers Microwave Surface IP67 2A - MW2AIP67

Product Overview

The Danlers 2A Microwave Presence Detection Switch IP67 (MW2AIP67) is a versatile solution designed for the automatic control of lighting, heating, and air conditioning systems in both indoor and outdoor environments. With an IP67 rating, it is well-suited for solid walls or ceilings, providing robust performance in various conditions. This microwave presence detector operates by emitting low power microwave signals, which allow it to detect movement within a significant range of up to 12m x 6m. The device automatically switches the load on when motion is detected and will turn it off after a designated time lag, which can be easily adjusted via internal dip switches. Its capacity to switch loads of up to 2 amps (500W) makes it ideal for applications in locations such as car parks, warehouses, and thoroughfares, ensuring efficient energy management while enhancing user convenience.

Specifications:

Detection range: max 12m at 6m high
Detection angle: 30° to 150°
Detection options: 10, 30, 50, 75, 100%
Time lag: 5sec, 30sec, 1min, 5min, 20min, 30min
Operating temperature: -30°C to 70°C
Switches up to 2 amps (500W) of most types of load
25mm glanded entry or 20mm via the supplied adaptor

Downloads

Download danlers-mw2aip67

Specification

Angle Of Detection	150 °
Battery Backup	Yes
Detection Range Maximum	12 m
Detection Range Minimum	6 m
Frequency	60 Hz
IP Rating	IP67
Motion Detection	Yes
Operating Temperature Maximum	70 °C
Operating Temperature Minimum	-35 °C
Sensor	Microwave
Surge Protected	Yes
Depth	110 mm
Height	65 mm
Weight	0.02 kg
Width	110 mm
