Product Overview

The Danlers 6A 2 Channel Microwave Presence Detection Switch IP67 (MW6A2CIP67) is a versatile solution designed for the automatic control of lighting, heating, and air conditioning systems in both indoor and outdoor environments. With an IP67 rating, it is well-suited for solid walls or ceilings, providing robust performance in various conditions. Two channels make it possible to switch two separate circuits.
This microwave presence detector operates by emitting low power microwave signals, which allow it to detect movement within a significant range of up to 12m x 6m. The device automatically switches the load on when motion is detected and will turn it off after a designated time lag, which can be easily adjusted via internal dip switches. Its capacity to switch loads of up to 2 amps (500W) makes it ideal for applications in locations such as car parks, warehouses, and thoroughfares, ensuring efficient energy management while enhancing user convenience.

Specifications:
Detection range: max 12m at 6m high
Detection angle: 30° to 150°
Detection options: 10, 30, 50, 75, 100%
Time lag: 5sec, 30sec, 1min, 5min, 20min, 30min
Operating temperature: -35°C to 70°C

Loading:
Switches up to 10 amps (2500W) of fluorescent lamps, either high frequency or switch start.
Switches up to 6 amps (1500W) of electronic or wire wound transformers
Switches up to 6 amps (1500W) compact fluorescent or LEDs and drivers, 2D etc.
Switches up to 1 amp (250W) of fans

Downloads

Download danlers-mwa62cip67

Specification

Angle Of Detection	150°
Battery Backup	Yes
Detection Range Maximum	12m
Detection Range Minimum	6m
Frequency	60Hz
IP Rating	IP67
Motion Detection	Yes
Operating Temperature Maximum	70°C
Operating Temperature Minimum	-35°C
Sensor	Microwave
Surge Protected	Yes
Depth	110mm
Height	65mm
Width	110mm
